Micro-Fit compatible connectors for compact power wiring
Micro-Fit compatible connectors are commonly selected for compact power connections in appliances, industrial modules, LED systems, battery equipment and control boards. Buyers compare pitch, circuit count, row layout, latch style, terminal material, wire gauge and mating header before confirming samples.
Micro-Fit Compatible Connector Specifications
Use this table as a purchasing checklist. Final values should be confirmed with drawings, samples and application requirements.
| Item | Reference | Buyer Confirmation |
|---|---|---|
| Connector type | Dual-row power connector | Housing, PCB header, crimp terminal |
| Pitch | 3.00mm class | Confirm footprint and mating height |
| Circuits | 2-24 circuit planning pages | Confirm row layout and cable direction |
| Terminal | Crimp terminal for wire harness | Wire gauge, plating, pull force |
| Application | Appliance, LED, battery, industrial control | Current, voltage, temperature and vibration |
Micro-Fit Compatible Model Pages
Start with common circuit counts below. Each model page can later expand into detailed housing, header and terminal pages.
2 Circuit Micro-Fit Compatible ConnectorFor compact two-circuit power and signal wiring.
4 Circuit Micro-Fit Compatible ConnectorCommon low-circuit appliance and LED module choice.
6 Circuit Micro-Fit Compatible ConnectorFor compact power boards and internal harnesses.
8 Circuit Micro-Fit Compatible ConnectorFor control boards with more power or signal circuits.
10 Circuit Micro-Fit Compatible ConnectorFor multi-circuit equipment harness assemblies.
12 Circuit Micro-Fit Compatible ConnectorFor higher circuit compact power connections.
What to confirm before ordering
Micro-Fit compatible connector application paths
Buyers usually compare Micro-Fit compatible connectors by application load, available PCB space and harness direction. These application paths help users choose the right circuit count before sending an RFQ.
Compact power boards
Use 2-6 circuit options for compact DC power, LED driver and small appliance modules.
Equipment harnesses
Use 6-10 circuit options when internal harnesses need power and signal lines in one latch connector.
High-circuit control boards
Use 10-12 circuit options for larger control boards that still need compact 3.00mm pitch packaging.
Request a Micro-Fit compatible connector quote
Send circuit count, pitch, housing or header requirement, terminal type, wire gauge, drawing, sample photo, application and annual demand.
Micro-Fit Compatible Connector FAQ
Click each question to expand the answer.
What is a Micro-Fit compatible connector used for?
It is used for compact power and signal wiring where buyers need a small dual-row connector with positive latch and crimp terminal support.
What should I confirm before quotation?
Confirm circuit count, pitch, mating header, housing latch, terminal, wire gauge, current, voltage and application environment.
Can HXHconnector help match housing, header and terminal?
Yes. Send a drawing, model, sample photo or physical sample, and HXHconnector can help confirm the matching set.
Is this page for original branded connectors?
This page is for Micro-Fit compatible connector selection. Final compatibility should be confirmed by drawings, samples and application testing.
Which circuit counts are common for Micro-Fit compatible connectors?
Common planning pages include 2, 4, 6, 8, 10 and 12 circuit options. Final availability should be confirmed by drawing and sample.
Can this connector be used for power boards?
Yes, Micro-Fit compatible connectors are often considered for compact power board wiring, but current, voltage, terminal and wire gauge must be confirmed.
