PH connectors for miniature PCB wire connection
The PH connector series is commonly used where a 2.00mm pitch wire-to-board connector is required for tight PCB space, compact battery leads, signal wiring or low-current power connection. Buyers usually compare pin count, wafer orientation, terminal compatibility, wire range, insertion direction and operating temperature before confirming a PH connector order.
PH Connector Series Specifications
Use this specification table as a purchasing checklist. Final values should be confirmed with HXHconnector drawings, samples and material requirements.
| Item | PH Series Reference | Buyer Confirmation |
|---|---|---|
| Connector type | Wire-to-board connector | Housing, wafer, terminal set |
| Pitch | 2.00mm class | Confirm PCB layout and mating height |
| Pin count | 2, 3, 4, 5, 6, 7, 8 pin options | Confirm circuit quantity and PCB space |
| Mounting direction | Vertical wafer and matching housing options | Confirm board direction and cable exit |
| Application | Battery pack, LED module, sensor, appliance PCB, instrument board | Confirm current, voltage and temperature |
PH Connector Pin Count Model Pages
Start with the common PH connector pin counts below. Each model page can later expand into housing, wafer and terminal pages for long-tail SEO traffic.
PH 3 Pin ConnectorFor three-circuit PCB connection.
PH 4 Pin ConnectorCommon appliance control board choice.
PH 6 Pin ConnectorFor multi-circuit wiring assemblies.
PH 5 Pin ConnectorFor compact sensor and control wiring.
PH 8 Pin ConnectorFor compact multi-circuit signal wiring.
What to confirm before ordering PH connectors
Applications for PH Connector Series
Battery pack wiring
Small battery leads, rechargeable packs and compact power modules.
LED and sensor boards
Miniature wire-to-board connection for LED strips, sensors and control modules.
Compact instruments
Electronic instruments, small appliances and space-limited PCB assemblies.
Request a PH connector quote
Send the PH connector pin count, housing or wafer requirement, terminal type, wire gauge, sample photo, drawing, application and annual demand. HXHconnector can help confirm matching parts before quotation.
PH RFQ checklist
PH Connector FAQ
Click each question to expand the answer. These interactions also help buyers compare PH connector requirements before sending an inquiry.
What is a PH connector series used for?
PH connector series products are commonly used for 2.00mm pitch wire-to-board connection in battery packs, LED modules, sensor boards, compact instruments and small appliance control boards.
How do I choose the right PH connector pin count?
Choose the PH connector pin count according to circuit quantity, PCB space, current load and cable assembly layout. You can start from the pin count model section and confirm details with drawings or samples.
Can HXHconnector supply PH housing, wafer and terminal together?
Yes. HXHconnector can support matching PH connector housing, wafer and terminal requirements. For faster confirmation, send photos, model numbers, wire gauge and PCB mounting direction through the RFQ form.
Is the PH connector suitable for appliance and industrial applications?
PH connector series products are commonly selected for compact appliance, LED, battery pack and industrial control wiring. Final selection should confirm current, voltage, temperature, housing material, terminal plating and equipment environment.
