ZH connectors for miniature 1.50mm PCB wire connection
The ZH connector series is commonly used where a 1.50mm pitch wire-to-board connector is required for tight PCB space, fine signal wiring, battery leads, LED boards or compact electronic assemblies. Buyers usually compare pin count, wafer orientation, terminal compatibility, wire range, insertion direction and operating temperature before confirming a ZH connector order.
ZH Connector Series Specifications
Use this specification table as a purchasing checklist. Final values should be confirmed with HXHconnector drawings, samples and material requirements.
| Item | ZH Series Reference | Buyer Confirmation |
|---|---|---|
| Connector type | Wire-to-board connector | Housing, wafer, terminal set |
| Pitch | 1.50mm class | Confirm PCB layout and mating height |
| Pin count | 2, 3, 4, 5, 6, 8 pin options | Confirm circuit quantity and PCB space |
| Mounting direction | Housing, wafer, terminal and cable assembly options | Confirm board direction and cable exit |
| Application | Sensor PCB, battery module, LED board, compact instrument, portable electronics | Confirm current, voltage and temperature |
ZH Connector Pin Count Model Pages
Start with the common ZH connector pin counts below. Each model page can later expand into housing, wafer and terminal pages for long-tail SEO traffic.
ZH 3 Pin ConnectorFor three-circuit compact PCB connection.
ZH 4 Pin ConnectorFor LED boards, sensors and compact controls.
ZH 5 Pin ConnectorFor small sensors and instrument wiring.
ZH 6 Pin ConnectorFor six-circuit fine signal wiring.
ZH 8 Pin ConnectorFor eight-circuit compact control modules.
What to confirm before ordering ZH connectors
Applications for ZH Connector Series
Sensor and battery modules
1.50mm wire-to-board connection for compact sensor PCBs, battery leads and small modules.
Portable electronics
Small device boards, compact controllers and fine-gauge wire harnesses.
LED and compact controls
LED modules, compact controls and low-power signal connections.
Request a ZH connector quote
Send the ZH connector pin count, housing or wafer requirement, terminal type, wire gauge, sample photo, drawing, application and annual demand. HXHconnector can help confirm matching parts before quotation.
ZH RFQ checklist
ZH Connector FAQ
Click each question to expand the answer. These interactions also help buyers compare ZH connector requirements before sending an inquiry.
What is the ZH connector series used for?
ZH connector series products are commonly used for 1.50mm pitch wire-to-board connection in compact sensors, battery modules, LED boards, portable electronics and space-limited PCB assemblies.
How do I choose the right ZH connector pin count?
Choose the ZH connector pin count according to circuit quantity, PCB space, current load and cable assembly layout. You can start from the pin count model section and confirm details with drawings or samples.
Can HXHconnector supply ZH housing, wafer and terminal together?
Yes. HXHconnector can support matching ZH connector housing, wafer and terminal requirements. For faster confirmation, send photos, model numbers, wire gauge and PCB mounting direction through the RFQ form.
Is ZH suitable for appliance, LED and compact electronics?
ZH connector series products are commonly selected for sensors, battery leads, LED modules, instruments and compact electronic assemblies. Final selection should confirm current, voltage, temperature, housing material, terminal plating, wire range and equipment environment.
